MAGUS CMA050 A10 C-mount Adapter

The price is valid only for the online store and may differ from the prices in retail stores.

For CMO stereomicroscopes. Magnification: 0.5х

Availability

Product ID	85144
Brand	MAGUS
Warranty	2 years
EAN	5905555025988
Package size (LxWxH)	6x2x3 cm
Suitable for sensors	1/2.5"–2/3"

Description

A beamsplitter with a port and a C-mount adapter are used to mount a digital camera on the MAGUS Stereo A6, A8, and A10 stereomicroscopes. A beamsplitter with a port is mounted between the microscope head and zoom objective. A digital camera on the C-mount adapter is installed in the port.

The adapter magnification is 0.5x. The maximum field of view without vignetting can be obtained on sensors from 1/2.5" to 2/3".

Recommended for cameras:

MAGUS CBF12 Digital Сamera
MAGUS CBF30 Digital Сamera
MAGUS CBF50 Digital Сamera
MAGUS CBF90 Digital Сamera
MAGUS CDF10 Digital Сamera
MAGUS CHD20 Digital Сamera
MAGUS CHD30 Digital Сamera
MAGUS CHD50 Digital Сamera

Compatibility:

MAGUS BOP A10 Beamsplitter with one port
MAGUS BTP A10 Beamsplitter with two ports
MAGUS Stereo A6 Stereomicroscope
MAGUS Stereo A8 Stereomicroscope
MAGUS Stereo A10 Stereomicroscope

Specifications

Product ID	85144
Brand	MAGUS
Warranty	2 years
EAN	5905555025988
Package size (LxWxH)	6x2x3 cm
Suitable for sensors	1/2.5"–2/3"
Magnification, x	0.5
Place of installation	MAGUS beamsplitter with one or two ports
