HU Ermenrich NetGeeks NP40 Digital Cable Tracker
Functions: TDR cable length measurement, cable testing, Port Flash function, cable tracing, PoE test
| Product ID | 82550 |
| Brand | Ermenrich |
| Warranty | 5 years |
| EAN | 5905555016948 |
| Package size (LxWxH) | 23x16x5 cm |
| Shipping Weight | 0.52 kg |
The Ermenrich NetGeeks NP40 multifunctional is a digital cable tester that is designed for tracing twisted pair and telephony, testing lines for faults and installation errors, measuring cable lengths and the distance to open or short circuits. The device will become an effective tool for technicians deploying and maintaining a computer or telephone network in an office, at a facility, or at home.
In the base mode of operation, the device can check the wires within the cable for damage: open circuits, short circuits, crossed pairs. In the cable length measurement mode, you can measure the total cable length within 200 meters as well as the distance to the break. TDR measurements, high accuracy, and calibration can be performed, if needed.
The Port Flash function can be used to find the exact port on the network switch or router to which the target cable is connected. The PoE test identifies the PSE type and detects midspan/endspan. The device also measures voltage and polarity. The tester receiver can be set to NCV mode for non-contact voltage detection.
The transmitter and receiver are powered by batteries (not included).
Key features:
- Cable tracing, testing lines for faults and installation errors
- Cable length measurement with the TDR technique (pulse reflectometry)
- Measuring the distance to open or short circuits
- PoE test with voltage measurement, identification of a PSE type, midspan/endspan identification
- Port Flash and NCV functions, powered by batteries
The kit includes:
- Transmitter
- Receiver
- Remote unit
- RJ11 patch cord
- RJ45 patch cord
- Alligator clip
- DC cable
- Earbuds
- Type-C USB cable
- Carry bag
- User manual and warranty card
| Product ID | 82550 |
| Brand | Ermenrich |
| Warranty | 5 years |
| EAN | 5905555016948 |
| Package size (LxWxH) | 23x16x5 cm |
| Shipping Weight | 0.52 kg |
| Transmitter | |
| Ports | PoE, Scan, Length/Flash, Cont |
| Tracing cable types | telephone, common wires, STP/UTP (CAT5E, CAT6, CAT6A) network cable |
| Testing cable types | STP/UTP (CAT5E, CAT6, CAT6A) network cable |
| Maximum length of the tested cable, m | 600 |
| Cable testing | + (open circuits, short circuits, crossed pairs, reversed pairs, split pairs, crosstalk) |
| Port flash function | +, (full duplex/half duplex, auto-nego/non-auto-nego, 10/100/1000Mbit/s) |
| Cable tracing | ✓ |
| PoE test | ✓ |
| Voltage polarity detection | ✓ |
| Cable length measurement | |
| Measuring method | Time-domain pulse reflectometry (TDR) |
| Units of measurement | meters/yards, feet |
| Measuring range, m | 2.5 — 200 |
| Error | 3 (±0.5m/1.6ft) |
| Measuring the distance to short circuit | ✓ |
| Calibration | + |
| PoE test | |
| Power source equipment (PSE) type test | standard (IEEE 802.3at/af)/non-standard |
| Operating voltage range (DC), V | 5 — 60 |
| Key features | |
| Protection | input voltage: 48V, current: 5mA |
| Display | LCD |
| Display resolution, px | 128х64 |
| Display backlight | ✓ |
| Power supply | charging via a USB Type-C cable (included), 3 rechargeable AAA batteries (not included) |
| Low battery status indicator | ✓ |
| Auto power off | 15 min, 60 min, 30 min |
| Operating temperature range,°C | −10… +60 (14… 140) |
| Operating humidity range, % | 20…70 |
| Receiver / Remote unit | |
| Ports | RJ45, earbuds |
| Adjustable sensitivity | ✓ |
| Non-contact voltage detection (NCV) | ✓ |
| Flash light | ✓ |
| Power supply | 9V battery (not included) |
| Operating temperature range,°C | −10… +60 (14… 140) |
| Operating humidity range, % | 20…70 |
