Levenhuk MED 40x Infinity Plan Achromatic Objective

Infinity-corrected. Spring-loaded frame. Magnification: 40x. Aperture: 0.65

Availability

Product ID	76077
Brand	Levenhuk, Inc., USA
Warranty	2
EAN	5905555004785
Package size (LxWxH)	3x6x3
Shipping Weight	0.102

Description

The Levenhuk MED 40x infinity plan achromatic objective features 40x magnification. It is designed for infinity-corrected microscopes. The glass optics eliminate chromatic aberrations and significantly flatten the field of view. Their main feature, which makes the transmitted images sharper, is the number of optical elements. In laboratory studies, a high-quality image is required. The objective's optics are housed in a metal body, the front lens is equipped with a spring-loaded frame.

The Levenhuk MED 40x infinity objective is an excellent choice for expanding any microbiologist's optical accessories kit.

The kit includes:

Objective
Plastic case

Specifications
Lens material	optical glass
Body material	copper
Optical design	plan achromatic
Magnification, x	40
Aperture	0.65
Working distance, mm	0.67
Parfocal distance, mm	45
Cover glass thickness, mm	0.17
Compatible tube length, mm	infinity
Thread type	WJ 4/5"*1/36"
Spring-loaded frame	yes
Oil immersion	no

Specifications

Product ID	76077
Brand	Levenhuk, Inc., USA
Warranty	2
EAN	5905555004785
Package size (LxWxH)	3x6x3
Shipping Weight	0.102
